ABB flexible conduits boost food safety and fight corrosion, which is the number one cause of downtime.
The next generation in liquidtight conduits.
Ingress protection and hygiene IP69K-rated conduit and fittings.
Demanding applications Stainless steel 316 liquidtight and system solutions for the most demanding corrosive environments, where extreme temperatures are encountered.
Hazardous protection LTFU and LTGC fittings are rated CSA Heavy duty per Canadian electrical code.
LTGC – General Purpose Liquidtight flexible metallic conduit, steel core with PVC jacket, CSA Certified
Flexible liquidtight metallic conduits
Cat. Number
Description
LTGCS01B-C
LFMC GP CSA 3/8IN BLK 30M/100FT
LTGCS01B-K
LFMC GP CSA 3/8IN BLK 150M/500FT
LTGCS01B-L
LFMC GP CSA 3/8IN BLK 300M/1000FT
LTGCS02B-C
LFMC GP CSA HD 1/2IN BLK 30M/100FT
LTGCS02B-K
LFMC GP CSA HD 1/2IN BLK 150M/500FT
LTGCS02B-L
LFMC GP CSA HD 1/2 BLK 300M/1000FT
LTGCS03B-C
LFMC GP CSA HD 3/4IN BLK 30M/100FT
LTGCS03B-K
LFMC GP CSA HD 3/4IN BLK 150M/500FT
LTGCS03B-L
LFMC GP CSA HD 3/4 BLK 300M/1000FT
LTGCS04B-C
LFMC GP CSA HD 1IN BLK 30M/100FT
LTGCS04B-J
LFMC GP CSA HD 1IN BLK 120M/400FT
LTGCS05B-B
LFMC GP CSA HD 1-1/4IN BLK 15M/50FT
LTGCS05B-E
LFMC GP CSA HD 1-1/4 BLK 60M/200FT
LTGCS06B-B
LFMC GP CSA HD 1-1/2IN BLK 15M/50FT
LTGCS06B-D
LFMC GP CSA HD 1-1/2 BLK 45M/150FT
LTGCS07B-B
LFMC GP CSA HD 2IN BLK 15M/50FT
LTGCS07B-C
LFMC GP CSA HD 2IN BLK 30M/100FT
LTGCS08B-A
LFMC GP CSA HD 2-1/2IN BLK 8M/25FT
LTGCS09B-A
LFMC GP CSA HD 3IN BLK 8M/25FT
LTGCS11B-A
LFMC GP CSA HD 4IN BLK 8M/25FT
( … ) show more products
( … ) show less products
Series 5300SST6 Stainless steel 316 liquidtight fittings
Flexible liquidtight metallic conduits
Cat. Number
Description
5331SST6
3/8 in - Insulated with steel ground cone - Straight
5341SST6
3/8 in - Insulated with steel ground cone - 45 deg
5351SST6
3/8 in - Insulated with steel ground cone - 90 deg
5331SST6-6
3/8 in - Insulated with SST 316 ground cone - Straight
5341SST6-6
3/8 in - Insulated with SST 316 ground cone - 45 deg
5351SST6-6
3/8 in - Insulated with SST 316 ground cone - 90 deg
5332SST6
1/2 in - Insulated with steel ground cone - Straight
5342SST6
1/2 in - Insulated with steel ground cone - 45 deg
5352SST6
1/2 in - Insulated with steel ground cone - 90 deg
5332SST6-6
1/2 in - Insulated with SST 316 ground cone - Straight
5342SST6-6
1/2 in - Insulated with SST 316 ground cone - 45 deg
5352SST6-6
1/2 in - Insulated with SST 316 ground cone - 90 deg
5333SST6
3/4 in - Insulated with steel ground cone - Straight
5343SST6
3/4 in - Insulated with steel ground cone - 45 deg
5353SST6
3/4 in - Insulated with steel ground cone - 90 deg
5333SST6-6
3/4 in - Insulated with SST 316 ground cone - Straight
5343SST6-6
3/4 in - Insulated with SST 316 ground cone - 45 deg
5353SST6-6
3/4 in - Insulated with SST 316 ground cone - 90 deg
5334SST6
1 in - Insulated with steel ground cone - Straight
5344SST6
1 in - Insulated with steel ground cone - 45 deg
5354SST6
1 in - Insulated with steel ground cone - 90 deg
5334SST6-6
1 in - Insulated with SST 316 ground cone - Straight
5344SST6-6
1 in - Insulated with SST 316 ground cone - 45 deg
5354SST6-6
1 in - Insulated with SST 316 ground cone - 90 deg
5335SST6
1 1/4 in - Insulated with steel ground cone - Straight
5345SST6
1 1/4 in - Insulated with steel ground cone - 45 deg
5355SST6
1 1/4 in - Insulated with steel ground cone - 90 deg
5335SST6-6
1 1/4 in - Insulated with SST 316 ground cone - Straight
5345SST6-6
1 1/4 in - Insulated with SST 316 ground cone - 45 deg
5355SST6-6
1 1/4 in - Insulated with SST 316 ground cone - 90 deg
5336SST6
1 1/2 in - Insulated with steel ground cone - Straight
5346SST6
1 1/2 in - Insulated with steel ground cone - 45 deg
5356SST6
1 1/2 in - Insulated with steel ground cone - 90 deg
5336SST6-6
1 1/2 in - Insulated with SST 316 ground cone - Straight
5346SST6-6
1 1/2 in - Insulated with SST 316 ground cone - 45 deg
5356SST6-6
1 1/2 in - Insulated with SST 316 ground cone - 90 deg
5337SST6
2 in - Insulated with steel ground cone - Straight
5347SST6
2 in - Insulated with steel ground cone - 45 deg
5357SST6
2 in - Insulated with steel ground cone - 90 deg
5337SST6-6
2 in - Insulated with SST 316 ground cone - Straight
5347SST6-6
2 in - Insulated with SST 316 ground cone - 45 deg
5357SST6-6
2 in - Insulated with SST 316 ground cone - 90 deg
( … ) show more products
( … ) show less products
Serie 5300SST6HT Stainless steel 316 Liquidtight fittings, high temperature
Flexible liquidtight metallic conduits
Cat. Number
Description
5331SST6HT
3/8 in - Insulated with steel ground cone - Straight
5341SST6HT
3/8 in - Insulated with steel ground cone - 45 deg
5351SST6HT
3/8 in - Insulated with steel ground cone - 90 deg
5331SST6-6HT
3/8 in - Insulated with SST 316 ground cone - Straight
5341SST6-6HT
3/8 in - Insulated with SST 316 ground cone - 45 deg
5351SST6-6HT
3/8 in - Insulated with SST 316 ground cone - 90 deg
5332SST6HT
1/2 in - Insulated with steel ground cone - Straight
5342SST6HT
1/2 in - Insulated with steel ground cone - 45 deg
5352SST6HT
1/2 in - Insulated with steel ground cone - 90 deg
5332SST6-6HT
1/2 in - Insulated with SST 316 ground cone - Straight
5342SST6-6HT
1/2 in - Insulated with SST 316 ground cone - 45 deg
5352SST6-6HT
1/2 in - Insulated with SST 316 ground cone - 90 deg
5333SST6HT
3/4 in - Insulated with steel ground cone - Straight
5343SST6HT
3/4 in - Insulated with steel ground cone - 45 deg
5353SST6HT
3/4 in - Insulated with steel ground cone - 90 deg
5333SST6-6HT
3/4 in - Insulated with SST 316 ground cone - Straight
5343SST6-6HT
3/4 in - Insulated with SST 316 ground cone - 45 deg
5353SST6-6HT
3/4 in - Insulated with SST 316 ground cone - 90 deg
5334SST6HT
1 in - Insulated with steel ground cone - Straight
5344SST6HT
1 in - Insulated with steel ground cone - 45 deg
5354SST6HT
1 in - Insulated with steel ground cone - 90 deg
5334SST6-6HT
1 in - Insulated with SST 316 ground cone - Straight
5344SST6-6HT
1 in - Insulated with SST 316 ground cone - 45 deg
5354SST6-6HT
1 in - Insulated with SST 316 ground cone - 90 deg
5335SST6HT
1 1/4 in - Insulated with steel ground cone - Straight
5345SST6HT
1 1/4 in - Insulated with steel ground cone - 45 deg
5355SST6HT
1 1/4 in - Insulated with steel ground cone - 90 deg
5335SST6-6HT
1 1/4 in - Insulated with SST 316 ground cone - Straight
5345SST6-6HT
1 1/4 in - Insulated with SST 316 ground cone - 45 deg
5355SST6-6HT
1 1/4 in - Insulated with SST 316 ground cone - 90 deg
5336SST6HT
1 1/2 in - Insulated with steel ground cone - Straight
5346SST6HT
1 1/2 in - Insulated with steel ground cone - 45 deg
5356SST6HT
1 1/2 in - Insulated with steel ground cone - 90 deg
5336SST6-6HT
1 1/2 in - Insulated with SST 316 ground cone - Straight
5346SST6-6HT
1 1/2 in - Insulated with SST 316 ground cone - 45 deg
5356SST6-6HT
1 1/2 in - Insulated with SST 316 ground cone - 90 deg
5337SST6HT
2 in - Insulated with steel ground cone - Straight
5347SST6HT
2 in - Insulated with steel ground cone - 45 deg
5357SST6HT
2 in - Insulated with steel ground cone - 90 deg
5337SST6-6HT
2 in - Insulated with SST 316 ground cone - Straight
5347SST6-6HT
2 in - Insulated with SST 316 ground cone - 45 deg
5357SST6-6HT
2 in - Insulated with SST 316 ground cone - 90 deg
( … ) show more products
( … ) show less products
Cable glands
Hygienic, corrosion-resistant cable glands for food processing machinery and preparation stations.
Compactness and hygienic design providing rigorous, dependable electrical connections.
Corrosion resistance Stainless steel and chemical resistant materials inhibit corrosion
Dust and liquidtight Exposure to dust, water, condensation and accidental spills of machine oils and lubricants. Suitable for splash zones.
Chemical resistance One piece, fully enclosed, smooth hygienic external casing. Compactness and hygienic design providing rigorous, dependable electrical connections.
Extreme temparatures A wide temperature range is available for more demanding applications.
Explosion protection Group I flameproof glands, ideal for all hazardous area applications.
FSCG series stainless steel cable glands for food and beverage – NSF approved
Cable glands
Cat. Number
Description
FSCG-M121
Thread M12, Cable range 3 to 6.5 mm, Thread length 6 mm
FSCG-M161
Thread M16, Cable range 5 to 10 mm, Thread length 7 mm
FSCG-M201
Thread M20, Cable range 6 to 12 mm, Thread length 10 mm
FSCG-M251
Thread M25, Cable range 12 to 17 mm, Thread length 14 mm
FSCG-0381
Thread NPT 3/8 in, Cable range 3 to 6.5 mm, Thread length 15.26 mm
FSCG-0382
Thread NPT 3/8 in, Cable range 5 to 10 mm, Thread length 15.26 mm
FSCG-0501
Thread NPT 1/2 in, Cable range 6 to 12 mm, Thread length 19.85 mm
FSCG-0751
Thread NPT 3/4 in, Cable range 12 to 17 mm, Thread length 20.15 mm
( … ) show more products
( … ) show less products
FSEM series stainless steel EMC cable glands for food and beverage – NSF approved
Cable glands
Cat. Number
Description
FSEM-M161
Thread M16, Cable range 5 to 10 mm, Thread length 7 mm
FSEM-M201
Thread M20, Cable range 6 to 12 mm, Thread length 10 mm
FSEM-M251
Thread M25, Cable range 12 to 17 mm, Thread length 14 mm
FSEM-0381
Thread NPT 3/8 in, Cable range 5 to 10 mm, Thread length 15.26 mm
FSEM-0501
Thread NPT 1/2 in, Cable range 6 to 12 mm, Thread length 19.85 mm
FSEM-0751
Thread NPT 3/4 in, Cable range 12 to 17 mm, Thread length 20.15 mm
( … ) show more products
( … ) show less products
Hazardous location fittings
Jacketed metal-clad cable fittings for hazardous locations.
STX and STEX fittings for hazardous location applications.
Continuity Provides grounding continuity of cable armour. Quick and easy installation without disassembly. Excellent pullout strength.
Ideal for storage locations Robust metallic construction. Safe operating temperature range: -40°C to +90°C (-40°F to +194°F).
Hazardous area protection Helps achieve safer, more reliable terminations in challenging industrial environments.
Star Teck (STX) hazardous location series fittings for Teck cable
Hazardous location fittings
Cat. Number
Description
STX050-462
Hub size of 1/2 inch. Range over jacket from 0.525 - 0.650 inch.
STX050-464
Hub size of 1/2 inch. Range over jacket from 0.600 - 0.760 inch.
STX075-465
Hub size of 3/4 inch. Range over jacket from 0.725 - 0.885 inch.
STX075-466
Hub size of 3/4 In Range over jacket from 0.825 - 0.985 inch.
STX100-467
Hub size of 1 inch. Range over jacket from 0.880 - 1.065 inch.
STX100-468
Hub size of 1 inch. Range over jacket from 1.025 - 1.205 inch.
STX125-469
Hub size of 1-1/4 inch. Range over jacket from 1.187 - 1.375 inch.
STX150-470
Hub size of 1-1/2 inch. Range over jacket from 1.350 - 1.625 inch.
STX150-550
Hub size of 1-1/2 inch. Range over jacket from 1.500 - 1.625 inch.
STX150-471
Hub size of 1-1/2 inch. Range over jacket from 1.600 - 1.875 inch.
STX200-472
Hub size of 2 inches. Range over jacket from 1.700 - 1.965 inch.
STX200-473
Hub size of 2 inches. Range over jacket from 1.900 - 2.187 inches.
STX200-474
Hub size of 2 inches. Range over jacket from 2.100 - 2.375 inches.
STX250-475
Hub size of 2-1/2 inches. Range over jacket from 2.300 - 2.565 inches.
STX250-476
Hub size of 2-1/2 inches. Range over jacket from 2.500 - 2.750 inches.
STX300-478
Hub size of 3 inches. Range over jacket from 2.580 - 2.840 inches.
STX300-479
Hub size of 3 inches. Range over jacket from 2.790 - 3.060 inches.
STX350-480
Hub size of 3-1/2 inches. Range over jacket from 3.00 - 3.27 inches.
STX350-481
Hub size of 3-1/2 inches. Range over jacket from 3.21 - 3.48 inches.
STX400-482
Hub size of 4 inches. Range over jacket from 3.420 - 3.690 inches.
STX400-483
Hub size of 4 inches. Range over jacket from 3.610 - 3.870 inches.
STX400-484
Hub size of 4 inches. Range over jacket from 3.810 - 4.030 inches.
STX400-485
Hub size of 4 inches. Range over jacket from 3.965 - 4.185 inches.
( … ) show more products
( … ) show less products
Star Teck Extreme XP (STEX) hazardous location series fittings for Teck cable
Hazardous location fittings
Cat. Number
Description
STEX075
Hub size of 3/4 inch. Range over jacket from 0.600 - 0.985 inch.
STEX100
Hub size of 1 inch. Range over jacket from 0.860 - 1.205 inch.
STEX125
Hub size of 1 1/4 inch. Range over jacket from 0.950 - 1.375 inch.
STEX150
Hub size of 1 1/2 inch. Range over jacket from 1.150 - 1.625 inch.
STEX200
Hub size of 2 inch. Range over jacket from 1.440 - 1.965 inch.
STEX250
Hub size of 2 1/2 inch. Range over jacket from 1.825 - 2.375 inch.
STEX300
Hub size of 3 inch. Range over jacket from 2.265 - 2.840 inch.
STEX350
Hub size of 3 1/2 inch. Range over jacket from 2.670 - 3.270 inch.
STEX400
Hub size of 4 inch. Range over jacket from 3.220 - 3.870 inch.
( … ) show more products
( … ) show less products
Wire and cable management
Innovative design and engineered materials for safety and continuity.
Easily bundle, secure and manage your cables.
Food safety The material used to produce Ty-Rap® detectable cable ties has recently been successfully tested for direct food contact.
High-vibration applications Ty-Met cable ties combine the convenience of a ball-lock fastening mechanism with a spring crimp that maintains tension after installation ensuring that the ties won’t slide down the cable bundle after they’re installed.
Ty-Rap Cable ties - Detectable
Wire and cable management
Cat. Number
Description
TY523M-NDT
Polyamide 6.6 - Length - 3.62 in (92 mm) Min. tensile strength - 18 lb (80 N)
TY524M-NDT
Polyamide 6.6 - Length - 5.4 in (137 mm) Min. tensile strength - 40 lb (180 N)
TY525M-NDT
Polyamide 6.6 - Length - 7.3 in (186 mm) Min. tensile strength - 50 lb (222 N)
TY25M-NDT
Polyamide 6.6 - Length - 7.3 in (186 mm) Min. tensile strength - 50 lb (222 N)
TY527M-NDT
Polyamide 6.6 - Length - 13.5 in (343 mm) Min. tensile strength - 120 lb (540 N)
TY27M-NDT
Polyamide 6.6 - Length - 13.5 in (343 mm) Min. tensile strength - 120 lb (540 N)
TY528M-NDT
Polyamide 6.6 - Length - 14.2 in (361 mm) Min. tensile strength - 50 lb (222 N)
